- Oil Temperature Sensor £15.00
- Outside Temperature Sensor £25.00
- Zada Tech Wideband AFR (Air Fuel Ratio) Controller with Bosch ADV Sensor £210.00
- Boost (MAP) Pressure Sensor £55.00
- Oil Pressure Sensor £55.00
- Throttle Position Sensor (TPS) £50.00
- Warning alarm buzzer £15.00
- Transmission Oil Temperature Sensor £15.00
- LED warning light £10.00
- Gearbox Oil Temperature Sensor £15.00
- Intercooler Air Temperature Sensor £35.00
- Exhaust Manifold Pressure Sensor £55.00
- Fuel Temperature Sensor £15.00
- Intake Air Temperature Sensor £35.00
- OBDII CAN bus hardware with cable £150.00
- Water Temperature Sensor £15.00
- Joystick Large Knob £8.00
- Differential Oil Temperature Sensor £15.00
- Fuel Pressure Sensor £55.00
- Exhaust Gas Temperature (EGT) K-Type thermocouple probe sensor £60.00
- Interior Temperature Sensor £25.00
- Air Lift or Air Suspension Pressure Sensor £55.00
- Zada Tech AFR (Air Fuel Ratio) Wideband Controller Functionality £20.00
Zada Tech Link ECU CAN Bus Multi Function Gauge Display
Universal multi Function gauge display compatible with Link ECU with CAN Bus output stream.
This is a universal kit that fits any car. Can be used on any double DIN head unit with an HDMI or AV video port. Additionally, it is compatible with our external LCD displays.
The system is capable of holding the peak values (marked by a yellow indicator), a dedicated list of peak values and resettable using the joystick. The instrument has its own peak value warning that can be set with the joystick, the needles change colour to red when a peak value is reached.
As well as the Link ECU's supported CAN Bus readings, we can incorporate our sensors within the system as extras. Please refer to the list on the right for the sensors that this gauge supports including the prices.
The base kit includes:
- The controller box (HDMI or AV output)
- Joystick and knob.
- Dedicated CAN Bus ports.
List of CAN Bus values:
Engine Speed, MAP, MGP, Barometric Pressure, TPS, Injector DC, Injector DC (Sec), Injector Pulse Width (Actual), ECT, IAT, ECU Volts, MAF, Gear Position, Injector Timing, Ignition Timing, Cam Inlet Bank 1, Cam Inlet Bank 2, Cam Exhaust Bank 1, Cam Exhaust Bank 2, Lambda 1, Lambda 2, Trig 1 Error Counter, Fault Codes, Fuel Pressure, Oil Temp, Oil Pressure, LF Wheel Speed, LR Wheel Speed, RF Wheel Speed, RR Wheel Speed, Knock Level 1, Knock Level 2, Knock Level 3, Knock Level 4, Knock Level 5, Knock Level 6, Knock Level 7, Knock Level 8, Limits Flags, APS (Main), Ethanol (%), Status Bit field
The kit and sensors come with 1 year warranty.
